Home Products YD-S1600 New High Speed Single Pass Printer

YD-S1600 New High Speed Single Pass Printer

1.  Adopting HP industrial printhead.

2.  High speed printing function: pattern, QR code, bar code,  images etc.

3.  Wide applications and high print resolution of 1200 × 1200 DPI.

4.  Print C, M, Y, K 4colors.

5. Print material:corrugated boxes, craft paper,pizza boxes,cartons,handbags, packaging boxes etc.

6.  Cost-effective, Eco-friendly and Easy to operate.



Category: HIGH SPEED PRINTER Tags: One pass printer, Single pass printer
  • Description
  • Specification

Description

Main features:

1.Using HP wide industrial printheads,single printhead can print width up to 297mm,the width can reach up to 885mm.

2. The maximum media width can reah up to 1600mm,which is more widely used and suitable for more media.

3.Belt-guided continuous operation high-speed printing, 1-4 colors adjustable, up to 360-1800 meters per minute.

4.Ultra wide design, suitable for the uninterupted production of corrugated boxes, cartons, handbags, paper bags,packaging boxes etc.

5.The sizes can be customized according to the demands of different manufacturers to meet the large

and small batch production, eliminating the complex platemaking process.

6.Using fast-drying water-based environmentally friendly ink, it dries immediately after printing,

and the pattern is waterproof and anti-fouling after printing.



Wide application:corrugated boxes, craft paper,pizza boxes,cartons,handbags, packaging boxes etc.

Specification

Model
YD-S1600
Print Width
885mm
Print Head
HP-FI-1000 Industrial print head
Print Resolution
1200*300 dpi,1200*600 dpi, 1200*1200 dpi
Print Speed
6-20m/min
Print Mode
one pass printing
Ink Color
C M Y K
Number of heads
1-3 pcs
Ink Type
Water-based Environmental Friendly Ink Pigment
Max bed Size
1600mm
Material Thickness
0-140mm
Material Type
Rigid and flexible material
Material
Carton, Paper Boxes, Paper Boxes,corrugated board etc.
Date Interface
RJ45(Gigabit Ethernet Port)
X/Y Positioning  Mode
Software
Power Requirement
220V/AC (±10%),50Hz;8.5KW
Printer Weight
1300KG
Printer Size
4130mm[L]*1755mm[W]*1860mm[H]
Working Environment
Separate,little sunlight,wentilated workshop.Temperature:18°C-30°C(64°F-86°F)Humidity:30%-70%(Non-Condensing)Ventilation equipment:Suggest Overhead exhaust fan,displacement 600 cfm
